SPECIFICATION:
Rating: 20mA 15V DC
SMD Type
SIZE: 6.2 x 3.0 x 3.5 mm
Operating force: 120±50gf
Dielectric strength: AC 250 V for 1 minute
Insulation resistance: 100 MΩ at 100V AC
Contact resistance: 100 MΩ Min.
Life Test: 1,000,000 Cycles
Approvals: RoHS
