• Compliances: SAEJ553; SAEJ1171

• Rating: 5-30A,32VDC.

• Interrupt Rating: 2,000A / 28VDC; 1 break operation.

• Typical life: 200 operations at 200% overload.

• Operating Temperature Rating: –30°C to 60°C

• Storage Temperature Rating: –30°C to 105°C

• Materials: UL-Rated 94V-0 thermoplastic body.

                    Nickel-plated copper alloy terminals.

• Termination: 5.2mm wide blades compatible with ATC type fuse blocks.

• Marking: Cover is color-coded to amperage ratings.

• Reset time:102-***A* (Type I) 200% of rating current within 30 seconds.
